Civil Dimension

Civil Dimension

PER-

SONS

 KGS SPEED
M.PS		 CAR INSIDE LIFT WELL

ENTER-

ANCE

 PIT OVER
HEAD		 GEARED

GEAR-

LESS
WIDTH DEPTH WIDTH DEPTH
05 340 0.60 1000 900 1500 1400 700 1400 4300
06 408 0.60 1200 1000 1600 1500 700 1400 4300
08 544 1,1.5 1300 1100 1900 1800 800 1600 4500 UP TO
3MPS
10 680 1,1.5 1350 1300 1900 2000 800 1600 4500 UP TO
3MPS
13 884 1.5 2000 1100 2500 1800 900 1600 4500 UP TO
3MPS
16 1088 1.5 2000 1300 2500 2100 1000 1600 4800 UP TO
3MPS
20 1360 1.5 2000 1500 2500 2400 1000 1800 4800 UP TO
3MPS
